Hey there, big guy.
Designed for complex projects with up to 16 camera chains.
Build around the most recognisable broadcast brands.
It’s ergonomic and modern design makes it a perfect place to spark creativity.
tech data
| Cameras | 8x Sony HDC3100 1x Sony HDC4300 2x Sony HDC3300R 1x Sony BRC-H900 4x Dreamchip + Bradley Remote Camera System |
| Lenses | 2x Telephoto lens (99x) 2x Telephoto lens (90x UHD) 1x Standard box lens (27x) 1x Standard lens (25x) 1x Standard lens (24x) 8x Standard lens (22x) 2x Wide lens (4.5x) 1x Wide lens (4.5x UHD) |
| Tripods | 13x Standard Tripod 1x ABC crane 12m 1x Orbiter Camera Seat |
| Video Switcher | Sony XVS 7000 |
| Monitoring | Vision: 6x 43′ Sony LCD Multiview Slomo desk: 6x 43′ Sony LCD Multiview Measure: 3x Sony 17′ OLED, 2x 43′ Sony LCD Multiview Tech desk: 2x 43′ Sony LCD Multiview Audio: 3x Craltech Quad LCD |
| Video Matrix | Evertz 128×256 |
| Measure | 2x Harris CMN-91 |
| Audio | Calrec ARGO S (DSP - 384ch) 4x Sennheiser SKM 6000 6x Sennheiser SK 5212 16x Sennheiser MKH 416 1x Surround Microphone DPA 5100 1x PC with 4ch audio card and Jingle player |
| Intercom | RTS ODIN, 128 port 4x RTS Digital Partyline 2x RTS Desktop/wall-mount 5x Wireless Riedel Bolero Quantum Prodys IP codec 2x Sonifex Commentary unit CM-CU21 |
| Video Processing | 2x LAWO vPro 8 3x Riedel MicroN |
| Video servers | 1x EVS VIA 12ch + 2x EVS RCU 1x EVS IPDirector 2x Grass Valley 3G Summit + 2x K2 Dyno Video Replay (6ch IN / 4ch OUT) 1X Sony XDS-1000 |
